High Energy Series

Pulse Energy (minimum)		10Hz	20Hz	50Hz		10Hz	20Hz	50Hz
mJ at 1064 nm		1100	1000	800		2000	1800	1600
mJ at 532 nm (Typ II doubling)		575	420	350		1000	900	800
mJ at 355 nm (Typ I doubling)		270	200	140		450	400	300
mJ at 266 nm		130	90	60		130	90	60

Pulse Duration
Fundamental at 1064 nm		10 nsec
Harmonics at 532, 355, 266 nm		9 nsec

Short Pulse Series

　

General Series

Wave Length		1064, 532, 355, 266, 213 nm

Repetition rate:		10 Hz / 20Hz

Pulse Energy		10 Hz		20 Hz
mJ at 1064 nm:		220 mJ		200 mJ
mJ at 532 nm:		110 mJ		90 mJ
mJ at 355 nm:		60 mJ		50 mJ
mJ at 266 nm:		30 mJ		25 mJ
mJ at 213 nm:		>4 mJ		4 mJ

Pulse duration at 1064 nm:		6 ns		5.5 ns
Pulse duration at 532 nm:		6 ns		5.5 ns
* At 10 Hz no water cooling is required.

　

		Model-300		Model-600
Wave Length		1064, 532, 355, 266, 213 nm
Pulse Length		7 ns
Repetition rate:		10 Hz (opt. 20, 30 or 50 Hz)

Pulse energy at 1064 nm:		320 mJ		750 mJ
Pulse energy at 532 nm:		180 mJ		400 mJ
Pulse energy at 355 nm:		100 mJ		200 mJ
Pulse energy at 266 nm:		40 mJ		90 mJ
* At 10 Hz no water cooling is required.

　

Wave Length		1064, 532, 355, 266, 213 nm
Pulse Duration		approx 7 nsec
Repetition rate:		10 Hz / 20Hz (other rates on request)
		10 Hz		20 Hz
Pulse energy at 1064 nm:		1300 mJ		1200 mJ
Pulse energy at 532 nm:		700 mJ		600 mJ
Pulse energy at 355 nm:		320 mJ		300 mJ
Pulse energy at 266 nm:		130 mJ		100 mJ
Pulse energy at 213 nm:		>24 mJ		24 mJ
* At 10 Hz no water cooling is required.

Pulsed Nd;Glass Lasers

It doesn't matter whether your requirements are modest or monstrous, we have the expertise and the experience to provide you with a reliable and cost-effective solution. So please contact us to discuss your specifications and let us show you examples of similar projects.

　

Intense Pulsed Light

Standard Machine Specifications:

Energy Per pulse: Up to 1500J

Pulse width: 100µs to 10ms

Repetition Rate: Single shot to 30Hz

　
